KIT FABRICATOR PRO EM500i (1210034)

Rubro: LINEA HEAVY INDUSTRIAL Marca: ESAB

Fabricator EM 500i is a heavy duty inverter controlled power sources for MIG/MAG and MMA (Stick) welding. Built to withstand rugged use which makes it a perfect solution for industrial usage. Ideal for heavy industries using solid and flux-cored wires together with Fabricator Feed wire-feeder.

• Wide Input voltage sustenance for stable welding output.
• Variable inductance control for better arc performance.
• Energy savings with high power factor, high efficiency and low idle power.
• IP 23 class for outdoor use.
• Insulation Class H for continuous heavy duty usage
• 4 Roll Drive Wire-feeder-smooth and  stable wire-feeding

---

Caracteristicas

Mains Supply, V/ Ph, HZ 380-440( ± 10%)/3, , 50/60

Permitted Load at 60% Duty Cycle (MIG/MMA), A 500

Permitted Load at 100% Duty Cycle (MIG/MMA), A 390

Current Range (MIG/ MMA), A 30-500

Voltage Range (MIG), V 15.5-39

Efficiency at Max Current, % 87

Power Factor Max Current 0.93

No Load Power, W < 50

Dimensions L x W x H, mm 710 × 325 × 470

Weight, Kg 62

Enclosure Class IP23S

Application Class S

Insulation Class H

Wire- Feeder Feed 364

Wire-Feed Drive 4 Roll

Wire Feed Speed, m/min 2.0-20.0

Wire Spool Capacity, kg 18

Max Spool Diameter, mm 300

Wire Dimensions, mm: MS/ SS/ AL 1.0 -1.6 Cored Wire 0.8 -1.6

---
